Options

ALL PRICES EXCLUDE VAT, DUTIES, AND LOCAL TAXES – EX WORKS

Dragonfly 28 – Sail Away Pricing

• Dragonfly 28 Touring – EUR 190,000

• Dragonfly 28 Performance – EUR 215,000

Dragonfly 28 Touring – Sail Away Specification Construction

All three hulls, the deck, and structural interior components are built using hand-laid fiberglass combined with Divinycell closed-cell foam core sandwich construction. Hull and deck are finished in white gelcoat, with non-skid surfaces also in white gelcoat.

The boat features an epoxy rudder and vinylester centerboard with an automatic kick-up system and cockpit-led downhaul. Epoxy primer and antifouling are applied to all three hulls, rudder, and centerboard (color of choice).

Each hull includes a forward collision bulkhead. The design incorporates curved GRP wings and two composite structural bulkheads in tempered vinylester. Additional bulkheads and interior panels are constructed in plywood with ash laminate, complemented by solid ash trim around the table and galley.

Additional features include:

• Rudder needle bearing in the upper rudder head

• Centerboard trunk closing mechanism for improved water flow

Below Deck

• Two large cabin windows

• Three acrylic/aluminum hatches (one per hull)

• Emergency hatch in aft cabin

• Manual bilge pump operable from cockpit

• Electric bilge pump

• 90-liter freshwater tank

• Two sinks with electric water system

• Marine toilet with 60L holding tank, manual pump-out to sea, and deck discharge

• Nine interior cushions (fabric selectable from standard collection)

Cockpit & Deck

• Stainless steel bow and aft pulpits, handrails, and bathing ladder

• Custom cabin stripe (color choice from Avery range; metallic optional)

• Two grey trampoline nets

• Aluminum tiller with removable telescopic extension

Winches & Deck Hardware:

• 2 × Andersen ST28 self-tailing winches (Swing Wing system)

• 2 × Andersen 40 winches on cabin top

• 2 × Andersen winch handles

• Ronstan deck organizers and genoa track system

• Mainsheet system: 1:6 + 1:24

• Boom vang/preventer: 1:4

• 14 halyard stoppers

• 4 stainless cleats with backing plates

Additional:

• Fire extinguisher (2 kg)

• Emergency storage box with dual access

Electrics & Electronics

• 12V system with main switch and fused panel

• Dual USB outlet (USB-A & USB-C)

• 70 Ah maintenance-free battery

• LED interior lighting

• LED navigation lights (stern and bow)

• Illuminated compass

Engine

Honda 15 HP (BF15DK2XRTU) ultra-long shaft, 4-stroke outboard with:

• Remote control and electric tilt

• 12L fuel tank

• High-thrust propeller

• Stainless mounting bracket

• Integrated charging to onboard batteries

Rig & Sails

• 12 m aluminum mast with two spreaders

• Aluminum boom with lazy jacks and two single-line reefs

• All control lines led to cockpit

Sail Plan:

• Mainsail (37 m²) – Elvström eXRP, 6 battens, 2 reef points

• Furling jib (19 m²) – Elvström eXRP, 3 battens

• Dyneema halyards and reefing lines

• Windex wind indicator

Additional:

• Foldable 1.60 m aluminum bowsprit

• Prepared for asymmetric spinnaker or Code 0

• 4 mooring lines and flagpole

Dragonfly 28 Performance – Sail Away

Includes all Touring specifications, plus:

• Upgraded Sail Plan:

• 43 m² Elvström EPEX mainsail (Technora Black, square-top)

• 21 m² EPEX furling jib

• Rigging Enhancements:

• Dyneema halyards and running rigging throughout

• Running backstays

• 13.5 m white-painted carbon mast

• Ronstan batten car system

• Performance Upgrades:

• Larger bowsprit (1.90 m)

• Enhanced mainsheet system (1:8 + 1:32)

• Stronger 7 mm Dyform forestay

• Wave-piercing floats (+20% buoyancy, +500L, +50 cm length)

• White-painted rudder (no antifouling)

Certification & Safety

• Unsinkable construction

• CE certified – Category B

Extras & Options

A comprehensive list of optional equipment is available for both Touring and Performance versions, including:

• Interior upgrades (elm wood finishes, flooring, refrigeration, heating)

• Cockpit enhancements (bimini, sprayhood, seating, deck hardware)

• Sail handling systems and additional sails

• Advanced electronics and navigation systems (Raymarine packages, solar, VHF, autopilot)

• Trailer and transport solutions

• Mooring and anchoring equipment

Delivery & Terms

• Prices include installation but exclude VAT, duties, and local taxes

• Electronics include installation but exclude calibration

• Prices subject to change without notice

• 5-year osmosis warranty (when epoxy treatment is applied by manufacturer)

• Ex works delivery
