EXTERIOR / LAMINATE

• Finish: Full female molded hulls & decks, exterior gelcoat finish with molded-in non-slip surface on deck areas.

• Hull Laminate: Infused Vinyl Ester (Modified epoxy) resin laminate of the entire hull laminate. Infused Polyester resin elsewhere. Laminate specifications are certified to CE standards.

MAST/BOOM/SAILS

• Clear anodised aluminium mast and boom. Single Spreader, 7/8 rig.

• Standing Rigging – Forestay 3/8 (10mm) 1 x 19 Dyform wire.

• Sidestays 3/8 (10mm) 1 x 19 Dyform wire

• Diamonds 5/16 (8mm) 1 x 19 Dyform wire.

• Halyards – Main halyard: 12 mm Spectra rope : Heavy duty shackle.

• Jib halyard: 8 mm Spectra rope. Heavy duty shackle.

• Topping lift: 10 mm rope, Heavy duty shackle.

• Spinnaker Halyard: 10mm rope with snap-shackle spliced to end.

• Boom outhaul.

• 2 x mainsail single line reefing fitted.

• Main halyard & reefing lines to be led back to cockpit through turning blocks and rope clutches.

• Fully battened dacron mainsail. Triple stitched reinforced construction. Leach adjustable batten end caps. Fibreglass sail battens + batten cars.

• Cruising mainsail cover with integrated lazy jack system.

• Self-tacking dacron headsail with furler. Curved headsail traveller track with end stops.

DECK EQUIPMENT

• Flush mounted hatches & portholes (12 in total)

• 4 x Forward deck hatches 470mm x 470mm

• 2 x Mid cabin deck hatches 470mm x 470mm

• 1 x Port mid cabin window hatch 507mm x 377mm

• 1 x Port bathroom window hatch 507mm x 377mm

• 1 x Port bathroom rear step portlight 600mm x 150mm

• 1 x Galley window hatch 507mm x 377mm

• 1 x Aft cabin window hatch 507mm x 377mm

• 1 x Aft cabin rear step portlight

• Fibreglass Deck Hatches:Forward anchor & storage hatches x 5

• 6 x Docking cleats: Bow, mid & stern cleats on each hull.

• 1 x Heavy duty mooring cleat on forward walkway.

• Ventilation: 2 x forward cabin hatch vents.

• Mast base turning blocks.

• 12 x Rope clutches.

• Sheet winches :

• 1 x 45 – 2 speed self tailing at stbd helm

• 2 x 40 – 2 speed self tailing at port and stbd helm

• 1 x 40 – 2 speed self tailing at mast

• Stanchions/Rails: High quality stanchions, bow rails and stern rails with 3 life-lines. 700mm high for premium offshore safety – exceeding CE Category A requirements.

• 2 x Transom access gates with pelican hook releases.

• 2 x side access gates with pelican hook releases.

• Aft swim ladder: Telescoping stainless aft swim ladder with flat tread for comfort.

NAVIGATION/HELM

• Steering compass at port & stbd helms.

• GRP Helm seats with ice box under port side and storage plus gas locker under stb side.

• Primary Helm (port) raised upholstered helm seat with folding backrest

FORWARD BEAM, CATWALK AND TRAMPOLINES

• Aluminium forebeam.

• Pelican striker and adjustable cable.

• 1 x Mooring rollers above foredeck.

• 2 x Anchor roller under deck. Permanent stowage position for Plough (Delta type) anchor.

• Catwalk in foam-sandwich fibreglass.

• Plastic coated open weave trampolines.

AFT BEAM AND DECK

• Moulded fibreglass Targa Bar with curved mainsheet track.

• Lounge seating at aft beam.

• Full width hard top over cockpit.

• Windows over helms for sail visibility.

• Dinghy davits mounted from aft targa supports.

STEERING/RUDDER SYSTEM

• Twin raised helm stations (dual) with: 2 X 32” composite steering wheels.

• Both wheels independently linked to steering system. – System offers back-up redundancy.

• Carbon fibre cross bar – rudder linkage.

LIGHTING / ELECTRICAL SYSTEM

• High quality DC electrical switch panel with circuit breakers, LED indicator lights and voltage display.

• Marine grade tinned electrical wiring with extensive use of heat sealed connectors.

• Batteries x 3 comprising: 2 x 12v 200Ah Deep Cycle House Gel Batteries to give total 400Ah. 1 x AGM Start batteries

• 230amp heavy duty isolation switch.

• 12v lighting : Numerous 12v interior lamps and courtesy lights throughout.

• Red night lights in cockpit for night sailing

• 3 x USB outlets:

• Nav desk

• Port fwd cabin

• Stbd fwd cabin

• 1x 12v outlet:

• Port helm

• CE approved navigation lights.

• Deck / Steaming combination light

• Mast head anchor / riding light.

• 2x 160w flush mounted solar panels and 25amp regulator.

PLUMBING /FRESH WATER TANKS

• Pressure hot & cold water system. Hot water storage system ( 40 litre / 10.5 gallons) . Hot & cold water to galley and both bathrooms.

• Galley fresh water tap is lever type ( Flickmaster or similar).

• Fresh water tank: 300 litres (79 gallons). Remote deck filler.

• Electric fresh water pump.

• Electric bilge pumps (2) with controls integral with master battery switch panel. Float Switches (2).

• Manual bilge pumps (2) in each hull.

• Through-hull fittings to Australian & CE survey standard.

• Manual toilets in each head.

• Port bathroom with separate shower stall. Starboard bathroom with dual purpose faucet & shower.

• Electric sump pump for shower drain.

• 2 x LPG bottles – 4.5kg aluminium.

• Fresh water tank gauge.

ENGINES

• Twin Yanmar 29hp saildrive diesel engines. Fresh water cooling, rubber isolation mounts on reinforced fibreglass bed with integral oil drip pan.

• Three blade fixed propellers.

• Dual engine controls at port helm station.

• Helm console mounted engine instruments with push button start, tachometers, engine monitoring, warning systems & engine hour meters.

• Fuel tanks: Total 360 litres (95 gallons)
